SONDORS Smart Step

The Smart Step is the first step-thru Ebike from SONDORS that is both approachable and easier to transport due to the unique foldable frame, covered by a one-year comprehensive warranty, and at a great price point that various.

Great ride comfort for a value-priced bike thanks to the coil suspension fork, plus-sized tires, and the upright-relaxed riding position, control systems are simple and intuitive, the grayscale LCD screen is highly visible even in direct sunlight

A rear-mounted geared hub motor from Bafang provides reliable power at 350 watts and is activated by either a cadence sensor or variable thumb throttle, the Shimano Tourney is a reliable derailleur and shifts smoothly with the RevoShift 7 grip shifter, good stopping power from Tektro Aries mechanical disk brakes

No accessories are included which means an extra cost if there are any accessories that you need, CST tires do not include puncture protection or reflective sidewalls, only available in one frame size which means it won’t be a good fit for tall riders.

Specs:

TOTAL WEIGHT:

55.6 lbs (25.21 kg)

BATTERY WEIGHT:

5.2 lbs (2.35 kg)

MOTOR WEIGHT:

6.5 lbs (2.94 kg)

FRAME MATERIAL:

6061 Aluminum Alloy

FRAME SIZES:

16 in (40.64 cm)

GEOMETRY MEASUREMENTS:

16″ Seat Tube, Reach, 20.25″ Standover Height, 32.5″ Minimum Saddle Height, 28″ Width 73″ Length, Folded Dimensions: 37″ Length, 39″ Height, 28″ Width

FRAME TYPES:

Step-Thru

FRAME COLORS:

Torch, Pearl, Black

FRAME FORK DETAILS:

Generic Coil Suspension Fork, 80mm Travel, 29.5mm Steel Stanchions, 100mm Hub Spacing, 9mm Axle with Nuts

FRAME REAR DETAILS:

135mm Hub Spacing, 12mm Threaded Axle with Nuts

ATTACHMENT POINTS:

Rear Rack Bosses, Fender Bosses

GEARING DETAILS:

7 Speed 1×7 Shimano Tourney Derailleur, Shimano MF-TZ500-7 14-28 Tooth Cassette

SHIFTER DETAILS:

Shimano RevoShift 7 Grip Shifter on Right

CRANKS:

Prowheel Forged Aluminum Alloy, 170mm Crank Arms, 52 Tooth Steel Chainring

PEDALS:

Wellgo Folding Platform, Plastic

Electronic Details

MOTOR BRAND:

Bafang

MOTOR TYPE:

Rear-Mounted Geared Hub

MOTOR NOMINAL OUTPUT:

350 watts

MOTOR PEAK OUTPUT:

450 watts

MOTOR TORQUE:

40 Newton meters

BATTERY BRAND:

LG 3500

BATTERY VOLTAGE:

36 volts

BATTERY AMP HOURS:

10.4 ah

BATTERY WATT HOURS:

374.4 wh

BATTERY CHEMISTRY:

Lithium-Ion

CHARGE TIME:

4 hours

ESTIMATED MIN RANGE:

20 miles (32 km)

ESTIMATED MAX RANGE:

30 miles (48 km)

DISPLAY TYPE:

3” GrayScale LCD, Adjustable Angle, Non-Removable

READOUTS:

Charge Level (5 Bars), Current Speed, Assist Level (1-5), Odometer, Trip Distance

DISPLAY ACCESSORIES:

Four-Button Pad on Left, Buttons: +, -, i, W, Power: Hold +, Walk Mode: Hold W, Settings: Hold + and –

DRIVE MODE:

Cadence Sensing Pedal Assist, Trigger Throttle

TOP SPEED:

20 mph (32 kph)

I love this bike it’s so comfortable and easy to fold and to put in the trunk and take it on the road, or stow away. It comes in two colors to choose from “White” and “Torch”.

For more information or how to order visit www.sonders.com
